Application area:

for low-temperature installation

Measuring range of thermometers:

0-120°C

Maximum working pressure [bar]:

10

Kvs [m3/h]:

10

Pump type:

25-6 180 electronic circulation pump

Maximum operating temperature [°C]:

90

Check valve installation placement:

on the return side

Barcode:

bar code packaging for retail sale

3-way mixing valve body material:

brass CW617N

Upper connection:

GW1

Connection:

GZ 6/4" for flat gasket

Pump included:

yes

Sealing material:

PTFE, EPDM

Product Photos

ferro_gmp602gpa_pp_01.jpg Download File

Assembly Instructions

ferro_manual_gmp602gpa.pdf Download File
