Gas ball valve F-M type G61 lever
The gas ball valve with lever G61 is a compact control element for domestic gas installations, ideal wherever a reliable 1/2" gas shut-off valve is required. Designed for DN15 systems, it supports safe operation of household appliances and fits standard residential connections.
The nominal pressure rating MOP5 (5 bar) and working temperature range T2 from -20°C to 60°C suit typical gas supply conditions in homes. The non-full-bore design helps maintain precise flow control, while the lever handle offers quick, intuitive operation. As a DN15 gas ball valve, it works well as a main or sectional shut-off point in small and medium-sized installations.
The body and ball made of brass provide high mechanical strength and resistance to corrosion, and PTFE ball seals contribute to smooth operation over time. Double NBR70 O-rings on the stem enhance tightness and reduce the risk of gas leakage. The nickel-free finish is a good option for users sensitive to nickel and for projects with stricter material requirements.
The nut–nipple 1/2" connection simplifies installation in existing pipework and fits common gas fittings, while the retail-ready packaging with barcode supports professional stock handling. The G61 gas ball valve with lever is a solid choice for installers and investors who value durable materials, safe operation, and convenient service of gas systems.
- Additional features:
- body and ball made from high quality brass CW617N
- Connection type:
- screw in/screw out
- Ball valve ball material :
- brass
- Material of stem seal:
- double o-ring NBR70
- Type of holder:
- lever
- NICKEL FREE:
- yes
- Nominal pressure [bar]:
- MOP5 (5 bar)
- Gland:
- no
- For multi-layer pipes:
- no
- Drain nozzle:
- no
- Suction strainer:
- no
- Air vent:
- no
- Full bore:
- no
- Rosette included:
- no
- Built-in filter:
- no
- Barcode:
- *W in packaging with a bar code for retail sale
- Ball sealing material :
- PTFE
- Operating temperature [°C]:
- T2 (-20°C to 60°C)
- Body material/assembly material:
- brass
- Media:
- gas
