Ball valve with filter, lever handle, 1" F-F
HERKULES
The HERKULES straight ball valve with lever and integrated filter is a robust component for water, glycol mixtures and compressed air installations. The full-bore design supports high flow, while the nut-to-nut 1" connection suits standard system layouts in residential and technical spaces.
The durable CW617N brass body works reliably at pressures up to 40 bar and temperatures up to 140°C, so the valve performs well in demanding conditions. A stainless steel filter element captures impurities in the medium, protecting downstream equipment and extending service intervals in the installation.
The brass ball with PTFE seals and double PTFE stem sealing reduces the risk of seizure and leakage over time. Nickel-free internal surfaces support safer contact with the medium, and the lever handle offers clear, quick control of the flow during operation or maintenance.
This HERKULES ball valve with filter is a solid choice for professional plumbing and heating systems where durability, stable operating parameters and convenient shut-off in a compact 121 mm body are essential.
- Additional features:
- • reinforced <br />• double stem sealing
- Maximum operating temperature [°C]:
- 140
- Nominal pressure [bar]:
- 40
- Ball valve ball material :
- brass
- Type of holder:
- lever
- Gland:
- yes
- NICKEL FREE:
- yes
- Full bore:
- yes
- Built-in filter:
- yes
- Connection type:
- screw out-screw out
- For multi-layer pipes:
- no
- Drain nozzle:
- no
- Suction strainer:
- no
- Air vent:
- no
- Rosette included:
- no
- Filter type:
- stainless steel
- Barcode:
- *W in packaging with a bar code for retail sale
- Ball sealing material :
- PTFE
- Material of stem seal:
- PTFE
- Media:
-
- 50% glycol
- compressed air
- water
- Body material/assembly material:
- brass
